Easy to Handle
Only 170 cm long, the HSD is shorter than a regular bike. It's a breeze to handle in tight spaces and goes easily where other bikes won't. The HSD flips up for convenient vertical parking and elevator rides, and can be flat-folded in seconds to go into bus racks and SUVs.

Comfier For Everyone
The HSD resizes in seconds to fit riders from 150 to 195 cm (4'11" - 6'5") so everybody in the family—from teens to grandparents—can enjoy the ride. The new Easy-Step frame design offers a comfortable upright riding position for riders tall or small, as well as easy mounts and dismounts.

Safety-Ready
The HSD gets its genes for strength and durability from the GSD. EFBE Prüftechnik GmbH, one of Europe's leading bicycle test laboratories, has tested the HSD frame and fork to 170 kg (374 lb) according to their own rigorous Tri-Test standard and the upcoming EN Cargo Bike standards

Powered by Bosch
The HSD is powered by Bosch's next generation Performance Line or Active Line Plus motors. The motors are smooth, silent, and deliver power with a wonderfully natural feeling. And of course every motor and battery system is backed by Bosch's best-in-class warranty and service.

A Whole Lot More
On top of all the standard features mentioned above, different HSD models are also packed with extras like Gates belt drives, Abus keyed-alike frame locks, and Cane Creek Thudbuster suspension seatposts.

• Size: 20”
• Series: HSD
• Wheel size: 20”
• Speed: 9 speed
• Frame size: one size
• Max Weight: 170kg
• Frame: Tern HSD, 6061-AL, patented design, Tern sliding dropouts
• Fork: Suntour custom for Tern, Chromoly steerer, 32mm stanchions, Thru-axle
• Stem: Tern Andros (G2), adjustable, forged construction, patented technology
• Headset: Tern Flux, cartridge bearings, Physis integrated
• Handlebars: Tern Sweep, 6061, Tern Andros adapted
• Bar Tape/Grips: Ergon
• Saddle: Tern HSD
• Seat Post: Tern Telescope, 34.9/30.9mm, 2014-AL
• Seat Clamp: Tern Collar, 6061-AL, 2pc
• Spokes: Stainless steel
• Rims: Tern Atlas H, wide 35 mm
• Tyres: Schwalbe Big Apple, 55-406, puncture protection, Reflex
• Shifters: Shimano Alivio, 1 x 9 spd, trigger
• Rear Derailleur: Shimano Alivio Shadow
• Crankset: Tern HSD custom
• Cassette/Freewheel: 11-32T, 9 spd
• Bottom Bracket: Motor integrated
• Chain: 9 spd, DHT for eBike, GST corrosion resistant coating
• Pedals: Urban with non-slip surface
• Motor: Bosch Active Line Plus (Gen 3), max speed 15.5mph (25kph)
• Battery: Bosch PowerPack 400
• Display: Bosch Purion, 4 mode selectable, walk assist
• Range: 26-69mile
• Bell Type: Aluminium
• Kickstand: Ursus, rear mount
• Front Light: Tern Valo 2.1, 45 lux/190 lumens
• Rear Light: Herrmans H-Trace, for eBike

**Some minor assembly is required. See our video (below) or consult our assembly guide for assistance.

Unfortunately, we are not able to process faulty or warranty bike returns through our warehouse. If your bike develops a fault, please take it to your nearest GO Outdoors store where we have a full workshop and trained mechanics who will be able to assist you.

Please note, this excludes Hathersage and Southport stores.
